24V/110V/220V Mini Size Liquid Level Switch Direct Aluminum Water Sensor(High-T Flanged Type,220VAC)
Product details
| Management number | 233789893 | Release Date | 2026/06/27 | List Price | US$101.37 | Model Number | 233789893 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
SwitchesOur default configuration: Power supply: AC220V, Connection type: G1 thread, Paddle type: Selectable as per requirement, Paddle and probe material: 304 stainless steel, Temperature tolerance range: -20 to 80°C.Note: Please select the correct voltage (24VDC, 220VAC, or 110VAC) based on your requirements when ordering. Connection type, temperature tolerance, pressure tolerance, rod length, protective tube length, and blade size can all be . Please contact us for special requests or custom configurations.Working Principle:Rotary Level Switch uses a drive shaft connected to a clutch. When not in contact with,he material, the motor keeps running normally, and when the blade touches the material,it forms a resistance to prevent the rotating mechanism from rotating. Under the action of resistance contact break, cut off the motor power to stop the electrode rotation, and output a contact signal. When the material drops the blade resistance disappears, themotor resumes rotation. Rotary Level Switch is specially designed to monitor the level of solids in silos, containers and chutes, and to reduce overflow, material waste and downtime by preventing silo overflow chute blockage and silo emptying.Parameters:1. Power supply: 220VAC(Default), 110VAC, 24VDC, 24VAC2. Power consumption: 4W3. Contact capacity: 5A/250VAC SPDT4. blade speed: 1r.p.m. (rpm)5. : (0.5~1)kgcm6. Material density: 0.4 g/cm7. Working temperature: (-20~80)°C (the highest temperature can 300°C subject to customization)8. Insulation resistance: 100MQ (500VDC)9. Dielectric strength: 1500VAC×1min10.Electrical Interface: M20×1.5==========High-concerned chemical : NoneCurrent : 5AMaterial : Stainless SteelSwitch Type : MICRO SWITCHWarranty : 1YearItem Type : SWITCHESOrigin : Mainland Current : 5AMaterial : STAINLESS STEELSwitch Type : MICRO SWITCHItem Type : SWITCHESOrigin : Mainland Blade Speed : 1 RPMVoltage Resistance : AC 1500V for 1 minuteHign-concerned Chemical : None,noneMeasuring : 1.0 NmDensity Suitability : 0.5g/cm³ or higherWorking Temperature : -20 to 80; High Temp: -20 to 400Power Supply : 220VAC / 110VAC/24VDCPower Consumption : 4WContact Capacity : SPDT 5A / 250VAC
- Switches
- 24V/110V/220V Mini Size Liquid Level Switch Direct Aluminum Water Sensor
| ASIN | B0G78F4WD6 |
|---|---|
| Color | High-T Flanged Type |
| Terminal | Blade |
| Brand Name | NTHZJIDVF |
| Part Number | IDACCAMAA-HIGH-TFLANGEDTYPE-220VAC |
| Switch Type | Bipolar Transistor |
| Circuit Type | 1-way |
| Contact Type | Normally Closed |
| Manufacturer | NTHZJIDVF |
| Material Type | Acrylonitrile Butadiene Styrene |
| Mounting Type | DIN Rail Mount |
| Connector Type | Clamp |
| Current Rating | 0.01 Amps |
| Operation Mode | OFF-NONE-ON |
| Item Dimensions | 0.39 x 0.39 x 0.39 inches |
| Number of Items | 1 |
| Contact Material | Alloy Steel |
| Operating Voltage | 1 Kilovolts |
| Specification Met | UL |
| Number of Positions | 1 |
| Lower Temperature Rating | 1 Degrees Celsius |
| Upper Temperature Rating | 1 Degrees Celsius |
| International Protection Rating | IP00 |
